- Posted by alex@engineeredsource.com
- On January 7, 2020
- 0 Comments
These are custom long 316 stainless steel screws at 8-32 X 3 in dimensions, manufactured domestically at a small batch of approximately 40 pieces. The parts were completed in a relatively quick turnaround time-frame of approximately 4 weeks from order, especially considering the holiday timing. To allow for the small quantity and speed the hex […]
Read More
- Posted by alex@engineeredsource.com
- On December 31, 2019
- 0 Comments
These are custom 316 stainless steel socket head cap screws at 10-32 X 1/2 and 10-32 X 3/8 in dimensions, manufactured domestically at a small batch of approximately 100 pieces. The parts were completed in a relatively quick turnaround time-frame of approximately 4 weeks from order, especially considering the holiday timing. To allow for the […]
Read More
- Posted by alex@engineeredsource.com
- On December 30, 2019
- 0 Comments
These custom nickel plated socket head screws were produced domestically using 4340 material instead of the originally requested 17-4PH version, with heat treatment to get the parts up to required 35-45 HRC hardness. 1/2-20 thread with 2A thread fit was incorporated with thread length of .77 inches. Overall length underneath the head was set at […]
Read More
- Posted by alex@engineeredsource.com
- On December 30, 2019
- 0 Comments
Slightly over 4,000 pieces of these custom captive shoulder screws were made domestically for our aerospace customer. An MS24671-32 part made using 302HQ DFARS compliant material was used as a base part to create this final version. Part of the 1/4-20 3A thread was turned down to a shoulder diameter of .175″ +/-.005 and length […]
Read More
- Posted by alex@engineeredsource.com
- On November 20, 2019
- 0 Comments
These custom flat socket head screws were manufactured domestically at 20,000 pieces in the 1.695″ overall length and the same quantity in 1.29″ overall length. 302 stainless steel material was used with plain passivated finish. Head diameter was .375″ and head height at .097″, with a 90 degree countersunk base. Partial thread of .75″ was […]
Read More
- Posted by alex@engineeredsource.com
- On October 30, 2019
- 0 Comments
These custom low profile socket head screws with a 6-lobe (torx) drive were manufactured domestically using 302 stainless steel material with a commercial passivated plain finish. 5,000 pieces of two sizes were produced: M10 – 1.5M X 65MM with a T-45 drive size and M8 – 1.25M X 65MM with a T-30 drive size. 26-30MM […]
Read More
- Posted by alex@engineeredsource.com
- On October 29, 2019
- 0 Comments
These custom low profile torx machine screws were manufactured domestically using 18-8 stainless steel material, at production volume of approximately 5,500 pieces. T10 size 6 lobe drive was incorporated and the head diameter at .262″ +/-.01″ and head height at .263″ +/-.01. 6-32 thread was selected for the .185″ of thread, followed by a lead […]
Read More
- Posted by alex@engineeredsource.com
- On July 16, 2019
- 0 Comments
We supplied these custom length shoulder bolts to our audio device manufacturer. The shoulder bolt is essentially an off-the-shelf 1/4 X 1 shoulder bolt with 10-24 rolled thread in 18-8 stainless steel material. Our customer was unable to use this version as-is due to the combined length of threaded portion and the machined fillet preceding […]
Read More
- Posted by alex@engineeredsource.com
- On July 10, 2019
- 0 Comments
We supplied these custom low head socket cap screws in alloy steel material with black oxide finish. Two different lengths were required by our customer – 28MM and 33MM under the head. We used COTS version of this DIN7984 socket cap screw at 35MM as the base part, then cutting and chamfering the parts to […]
Read More
- Posted by alex@engineeredsource.com
- On July 10, 2019
- 0 Comments
We supplied 54 pieces of these custom aerospace socket head cap screws to our long time customer. They were made in the USA using 18-8 stainless steel material (no DFARS requirement on these) with a broached 9/64″ hex socket drive with min .077″ engagement depth. 1″ of the overall 4.25″ length under the head was […]
Read More
