Project Description

These custom low profile socket head screws with a  6-lobe (torx) drive were manufactured domestically using 302 stainless steel material with a commercial passivated plain finish.  5,000 pieces of two sizes were produced: M10 – 1.5M X 65MM with a T-45 drive size and M8 – 1.25M X 65MM with a T-30 drive size.  26-30MM of thread was incorporated on the larger version and 22-25MM on the smaller diameter part.  The low profile & 6-lobe drive combination is relatively tricky, especially for these larger diameters as additional controls in tooling are required to avoid flowering on the outside profile of the head.

Large quantities of these custom made low profile socket head screws would be best supplied on a 12 month blanket purchase order basis.  The Blanket Order concept allows the customer to access the large quantity cost savings without paying upfront for the entire large quantity order. Instead we take on the burden of carrying the bulk inventory and only release the parts as needed, or often on a pre-scheduled basis provided by the customer.

Project Details
