Project Description

We supplied 54 pieces of these custom aerospace socket head cap screws to our long time customer. They were made in the USA using 18-8 stainless steel material (no DFARS requirement on these) with a broached 9/64″ hex socket drive with min .077″ engagement depth. 1″ of the overall 4.25″ length under the head was threaded at 8-32. Due to the smaller quantity required the thread was cut rather than rolled. Material certs and a certificate of conformance was provided but no FAIR was required for this specific part.

Project Details
