- Posted by alex@engineeredsource.com
- On May 29, 2019
- 0 Comments
We supply these tricky custom 17-7PH springs to our aerospace customer – unlike the other compression and extension 17-7PH springs we supply the same customer, these are C shaped with two .165″ length oval openings. The material thickness was set to .020″ and the outside diameter at .550-.555″. The angle between the ends was the […]
Read More
- Posted by alex@engineeredsource.com
- On May 22, 2019
- 0 Comments
These custom modified button socket screws were made using standard off the shelf M3 X 0.5MM button socket cap screws. The COTS version was modified to an overall length of 7.24MM, inclusive of the head height. The dog point prior to the radius start was set at a length of .015″ and diameter of .090″. […]
Read More
- Posted by alex@engineeredsource.com
- On May 9, 2019
- 0 Comments
These custom silicon bronze slotted machine screws were manufactured domestically with a fillister head diameter of 0.5″. 2,000 pieces in total were produced using C65500 half hard siliconze bronze material. Head height was set at .110 +/- .005″ and the thread length underneath the head was set at .75 +/- .01″. 1/4-20 thread was incorporated […]
Read More
- Posted by alex@engineeredsource.com
- On May 6, 2019
- 0 Comments
These custom slotted machine screws were made at a smaller 150 piece quantity for our architectural design customer. They were made domestically using 18-8 stainless steel material with a relatively fast turnaround time of 2 weeks from order. We replicated a sample part provided by our customer in the absence of a drawing. 1/4-20 thread […]
Read More
- Posted by alex@engineeredsource.com
- On March 19, 2019
- 0 Comments
In getting these custom modified socket cap screws made we started with standard off the shelf 2-56 X 3/4″ socket cap screws in 18-8 stainless steel material – our customer required the length to be cut and chamfered down to .745″ and a groove to be added 1/8″ from the point. The groove measured .052″ […]
Read More
- Posted by alex@engineeredsource.com
- On January 29, 2019
- 0 Comments
Our customer was in urgent need when she ordered this custom machined aluminum hardware and was having a hard time finding anyone to run a small quantity while maintaining a fast turnaround. We were able to come to the rescue with 24 total pieces and 16 days of lead time to get the parts completed. […]
Read More
- Posted by alex@engineeredsource.com
- On January 7, 2019
- 0 Comments
Our architectural element construction customer ordered approximately 4,000 pcs of these custom large stainless steel spacers. 5/16-18 thread was incorporated internally, 1-1/4 inches of thread min on each side. The gap between the two sides of thread was drilled all the way through for improved production time, allowing the entire part to be drilled through […]
Read More
- Posted by alex@engineeredsource.com
- On December 7, 2018
- 0 Comments
Approximately 34,000 pieces of these custom bead blast flat socket screws were supplied to our customer in the defense manufacturing sector. Half the parts were set at 1.29″ length while the other half set to 1.695″ length. The same 1/4-28 thread was incorporated on both parts and the socket drive was cold headed. A spherical […]
Read More
- Posted by alex@engineeredsource.com
- On December 3, 2018
- 0 Comments
We supplied our customer a short run supply of these custom slotted pins with partial 6-32 thread. Just over 200 pieces were produced domestically using 304 stainless steel material. The 6-32 thread length was set at 0.18″ and all other dimensions were derived from the samples our customer provided us. These parts were relatively simple […]
Read More
- Posted by alex@engineeredsource.com
- On November 29, 2018
- 0 Comments
We provide our customer a small batch of these custom stainless steel double end studs at just over 100 pieces. They wanted to replicate existing parts but did not have any drawings or prints. We used a sample piece provided to replicate all dimensions to a +/-.01″ tolerance. 1/4-20 thread is incorporated on the larger […]
Read More
