- Posted by alex@engineeredsource.com
- On September 12, 2019
- 0 Comments
These custom precision steel pins were manufactured domestically for our customer involved in water treatment product manufacturing. 1018 CRS material was used with plain finish. The drive-less head measures .060″ in height and .290″ for the diameter, +/-.005″. The shoulder portion was the most critical with a diameter of .195″ +/- .001″ and a slight […]
Read More
- Posted by alex@engineeredsource.com
- On September 6, 2019
- 0 Comments
These custom 17-4PH dowel pins were manufactured domestically at 6,000 pieces. DFARS 17-4PH stainless steel material was used, per AMS5622 with H900 heat treatment required. Overall length was 22.8MM +0/-.4 and the critical diameter of the pins measured 5MM +0/-.013. Our internal part number for this custom dowel pin is 12901978 and typical lead time is […]
Read More
- Posted by alex@engineeredsource.com
- On August 8, 2019
- 0 Comments
We supply these custom aerospace compression springs to our aerospace components manufacturing customer. 17-7PH stainless steel material is used for the domestic production of these parts, per AMS 5673-F. Our production runs are typically in the smaller 500 piece quantity range for this specific spring, with lead time at 8-10 weeks. That lead time includes […]
Read More
- Posted by alex@engineeredsource.com
- On July 19, 2019
- 0 Comments
These are tiered custom threaded stainless pins created for an audio equipment manufacturer in 18-8 stainless steel material. Production was done domestically with a lead time of 5-6 weeks from order. The overall length of the part is at 1.4″ inclusive of .90″ of M3 coarse thread and .37″ of 10-32 thread. Multiple shoulder steps […]
Read More
- Posted by alex@engineeredsource.com
- On June 21, 2019
- 0 Comments
We supplied our long time medical device customer 2,500 pieces of these tricky custom stainless slotted pins. Production was done domestically using 416 stainless steel material – the original design called out for 17-4PH stainless steel material but that was found to be unnecessary for the relatively simple application. 416 SS provided a much more […]
Read More
- Posted by alex@engineeredsource.com
- On June 7, 2019
- 0 Comments
These custom 52100 dowel pins were fairly ordinary in dimensional requirements but the material was quite tricky and time intensive to procure. C-52100 DFARS material per S5452100-22810A specification was used with 91.5 ksi tensile strength. Heat treatment was performed to achieve hardness of 81-83.5 HRA per customer requirements. Material certs and a certificate of conformance […]
Read More
- Posted by alex@engineeredsource.com
- On May 29, 2019
- 0 Comments
We supply these tricky custom 17-7PH springs to our aerospace customer – unlike the other compression and extension 17-7PH springs we supply the same customer, these are C shaped with two .165″ length oval openings. The material thickness was set to .020″ and the outside diameter at .550-.555″. The angle between the ends was the […]
Read More
- Posted by alex@engineeredsource.com
- On March 27, 2019
- 0 Comments
We supply our customer these custom eccentric shafts on a revolving blanket purchase order basis, typically at 350 pieces required annually. 431 material per AMS 5628 material was used to manufacture these tricky parts, with heat treat, dicronite finish per AMS 2530 not to exceed .0002″ in thickness. Dimensional tolerances were very stringent on these […]
Read More
- Posted by alex@engineeredsource.com
- On March 22, 2019
- 0 Comments
These custom 17-7PH compression springs were manufactured domestically and is intended for aerospace manufacturing applications. 17-7 PH Stainless steel material per AMS 5678 was used and the parts were passivated per MIL-S-5002. Heat treat was specificed per MIL-H-6875 and we also had to run the springs 100% through penetrant inspection in accordinace with MIL-STD-6866 Type […]
Read More
- Posted by alex@engineeredsource.com
- On March 1, 2019
- 0 Comments
These custom titanium dowel pins were manufactured domestically using ASTM B348 Grade 5 material. Our customer was a US University based physics research facility and per their request a material certificate with a certificate of conformance was provided with the parts. The 1/16 diameter had a tolerance of +/- .005. Large quantities of these custom […]
Read More
