- Posted by alex@engineeredsource.com
- On August 22, 2017
- 0 Comments
These are custom button head socket screws with half dog point used in an aerospace assembly application by our long time customer. 18-8 material is used to domestically manufacture these parts and the half dog point measures .225-.235 diameter by .150-.170 inches in length. The screw itself measures 5/16-24 X 1″ and we had these […]
Read More
- Posted by alex@engineeredsource.com
- On August 10, 2017
- 0 Comments
These are special made NAS 1351C4H16 aerospace socket head cap screws in 302HQ stainless steel material. They are manufactured domestically within the USA using DFARS compliant material with production running at typically 50,000 to 60,000 pieces. We supply these NAS socket screws to our long time aerospace customer at revolving annual blanket purchase terms. 1/4-28 […]
Read More
- Posted by alex@engineeredsource.com
- On August 4, 2017
- 0 Comments
These are custom machined double end studs used for aerospace applications and in our case specifically for helicopter repair. 17-4 material is used and the 10-32 UNJF-3A thread is cut after the drilled hole process and machined operations are completed. A 3/32 hex recess with a .225″ deep cavity is created on one side using […]
Read More
- Posted by alex@engineeredsource.com
- On June 27, 2017
- 0 Comments
These are custom metric Invar 36 screws that we supply the University of Montreal in Canada at approximately 50 pieces per order. They are manufactured domestically in the United States with a lead time of 2 weeks and are provided with all required certifications. Our relationships with factories all over the United States and abroad […]
Read More
- Posted by alex@engineeredsource.com
- On June 9, 2017
- 0 Comments
These are custom stainless steel socket cap screws made domestically using 303 stainless steel at just 102 pieces. We supply this part to our long time aerospace customer approximately once a year with full paperwork. It measures 8-32 X 4-1/2 and had a relatively short lead time of 1 week for production. Our internal part […]
Read More
- Posted by alex@engineeredsource.com
- On May 2, 2017
- 0 Comments
These are custom drilled socket head cap screws we supplied our customer that specializes in aerospace parts repair. They are made domestically in the USA using 17-4 PH/AMS 5643 material with AMS 2759/3, H1100 (30-37 Rc) heat treat, heavy medium sand blast, and finally passivation. The socket head is drilled in four places at 60 […]
Read More
- Posted by alex@engineeredsource.com
- On April 14, 2017
- 0 Comments
These are custom hex nuts we supplied to one of our long time aerospace customers, made using 18-8 stainless steel to print with a single drilled corner on each nut. The parts were domestically made with a lead time of 4-6 weeks for the initial release and incorporated a fine 1/4-28 thread. In terms of […]
Read More
- Posted by alex@engineeredsource.com
- On March 21, 2017
- 0 Comments
This is a small batch of custom stainless steel dowel pins manufactured domestically in the USA at just 36 pieces. 303 stainless steel was used and the custom dowel pins measure .1160 at the diameter by .625 inches in length. The diameter was the most critical dimension with a tolerance of +/-.0001″. Both sides were […]
Read More
- Posted by alex@engineeredsource.com
- On March 9, 2017
- 0 Comments
These are specialty nylon pellet set screws we supply our long time aerospace customer on scheduled release blanket purchase order basis. The cup point set screws are made in the USA using 18-8 stainless steel material and are then run through the nylon pellet secondary operation. Our customer using approximately 500 pieces every six months […]
Read More
- Posted by alex@engineeredsource.com
- On March 3, 2017
- 0 Comments
These are custom stainless aerospace pins we supply on a production to order basis. Only one side is chamfered to the customer’s requirements and the custom parts are run through passivation prior to shipment. They measure .310 at the diameter and 3″ +/.02 in length. To the customer’s specifications, these custom pins are manufactured in […]
Read More
