- Posted by alex@engineeredsource.com
- On July 3, 2019
- 0 Comments
These custom precision aluminum plates are manufactured using 6061-T6 material with plain finish, with our customer providing their own black and clear anodizing processes. The plates are .100 +.002/-.005″ in thickness and 2.5 +/- .04″ in overall length. The rivet counterbores are machined to achieve the precise dimensional requirements on the drawing, with the drilled […]
Read More
- Posted by alex@engineeredsource.com
- On July 3, 2019
- 0 Comments
These custom steel spring washers were manufactured using high carbon steel material heat treated to 38-45 HRC with black oxide finish. When flat, the inside diameter measures .126″ and the outside diameter is at .245″. The thickness is set to .004″ +/- .005″ with our production parts mostly measuring around .007″ in thickness. In it’s […]
Read More
- Posted by alex@engineeredsource.com
- On July 3, 2019
- 0 Comments
These custom metric button socket cap screws are made using alloy steel material at 32-36 HRC with black oxide finish. The head diameter is 5.7MM and head height at 1.65MM, with a 2.0MM hex drive size. The overall length underneath the head is set at 6MM, of which 2.5MM is designed to be the un-threaded […]
Read More
- Posted by alex@engineeredsource.com
- On June 28, 2019
- 0 Comments
We supply these custom grade 5 shoulder bolts to our long time customer with recurring annual blanket purchase orders, typically with annual usage ranging between 20,000 and 25,000 pieces. They are domestically manufactured to a grade 5 standard with commercial zinc, bake and clear chromate finish. The shoulder measures .40″ in diameter by .50″ in […]
Read More
- Posted by alex@engineeredsource.com
- On June 28, 2019
- 0 Comments
We supply these custom hex shoulder screws to our Canadian customer, with the shoulder measuring .425 +/-.002 by 1.650 +.005/-.000 in length. 5/16-18 thread was incorporated measuring .50″ in length including the unthreaded portion before the rolled thread begins. .055 radius hole was then drilled at .102″ from the end of the threaded portion. 4340 […]
Read More
- Posted by alex@engineeredsource.com
- On June 21, 2019
- 0 Comments
We had 10,000 pieces of these custom coupling nuts with nylon patch produced for our customer using 18-8 stainless steel material with partial internal thread. The drilled hole depth was at 19MM max and 16MM of that depth was to be threaded. Across the flats measures .500″ and overall length at 1.5″. The undrilled side […]
Read More
- Posted by alex@engineeredsource.com
- On June 21, 2019
- 0 Comments
We supplied our long time medical device customer 2,500 pieces of these tricky custom stainless slotted pins. Production was done domestically using 416 stainless steel material – the original design called out for 17-4PH stainless steel material but that was found to be unnecessary for the relatively simple application. 416 SS provided a much more […]
Read More
- Posted by alex@engineeredsource.com
- On June 14, 2019
- 0 Comments
We had 50,000 pcs of these custom 316L socket screws produced domestically for our action sports product customer. Our goal was to recreate a 70 degree taper on the head profile originally accomplished using a machined secondary process. The hardness of 316L stainless steel material made this is outcome difficult to achieve using a cold […]
Read More
- Posted by alex@engineeredsource.com
- On June 7, 2019
- 0 Comments
These custom 52100 dowel pins were fairly ordinary in dimensional requirements but the material was quite tricky and time intensive to procure. C-52100 DFARS material per S5452100-22810A specification was used with 91.5 ksi tensile strength. Heat treatment was performed to achieve hardness of 81-83.5 HRA per customer requirements. Material certs and a certificate of conformance […]
Read More
- Posted by alex@engineeredsource.com
- On June 6, 2019
- 0 Comments
These custom precision aluminum stamped plates work in combination with a separate custom aluminum plate in a medical device application. The parts are extremely tight tolerance dimensionally and are clear anodized prior to their final use. The overall length is set at 2.5″ and overall width at its maximum point is set at 1.70″. Thickness […]
Read More
