- Posted by alex@engineeredsource.com
- On June 27, 2018
- 0 Comments
These are custom drain plugs we supply one of our core customers on a revolving annual blanket purchase order basis. They are supplied in 3 separate pieces that are then assembled around the paneling on assembly floor. While a more expensive and more intricate option was made available to our customer initially, this pictured 3-piece […]
Read More
- Posted by alex@engineeredsource.com
- On June 1, 2018
- 0 Comments
These custom regulator vented plugs are a perfect example of the large number of custom automotive hardware components we supply our customer base. We worked with the customer through a number of design iterations to forgo an initial design that included a brazed component and instead go towards a design shown here with a vented […]
Read More
- Posted by alex@engineeredsource.com
- On May 29, 2018
- 0 Comments
These are custom slotted reverse drive machine screws made domestically in the USA using low carbon steel material with commercial zinc and clear finish. Approximately 12,000 pcs were produced with a lead time of 8-10 weeks. The heads were cold headed and the slotting was done as the last stage in the process prior to […]
Read More
- Posted by alex@engineeredsource.com
- On May 10, 2018
- 0 Comments
These custom slotted flat copper machine screws are one of multiple sizes we have supplied our customer over the years. They are custom made each time as ordered due to relatively small usage and are typically shipped within 2-3 weeks of order. This specific 4/40 X 5/16 version was produced domestically at 1,100 pcs under […]
Read More
- Posted by alex@engineeredsource.com
- On May 3, 2018
- 0 Comments
Over the years we have provided countless custom knurled hardware pieces – below is a snapshot of a custom bolt we are working on producing for a customer that is intended to be hammered into a predrilled steel plate. We noticed that the spec calls out for diamond knurling but realized that probably won’t work […]
Read More
- Posted by alex@engineeredsource.com
- On April 24, 2018
- 0 Comments
These are custom eye bolts we supplied in 304 stainless steel material, with nuts and washers per our customers requirements. 5/16″ coarse thread and bar stock was used and the parts were bent to create a 1-3/8″ inside eye diameter and approximately 1″ of thread. Material certs were made available to the customer with the […]
Read More
- Posted by alex@engineeredsource.com
- On March 15, 2018
- 0 Comments
These are custom brass bushings we supply our automotive customer on a recurring blanket purchase order basis, with monthly releases based on their usage. They are manufactured overseas in Taiwan and maintain +/-.009 tolerance on the outside and inside diameter, as well as the length. The inside diameter is set at 0.500 inches, the outside […]
Read More
- Posted by alex@engineeredsource.com
- On February 16, 2018
- 0 Comments
These are one of the custom brass inserts we supply our long time customer that had production facilities in the US and in Mexico. We initially ran a test production cycle of 300 pieces for them to test in their assembly prior to committing for the full 10,000 pcs required in their first batch. Plain […]
Read More
- Posted by alex@engineeredsource.com
- On January 19, 2018
- 0 Comments
These are custom stainless standoffs made using 304 stainless steel material in accordance with ASTM A276 and passivated to ASTM A380. Approximately 100,000 pieces were produced domestically with full certifications. 4-40 thread was incorporated on both male and female parts, with the male part measuring .750 inches and female hex measuring .320 inches in length. […]
Read More
- Posted by alex@engineeredsource.com
- On December 5, 2017
- 0 Comments
Pictured here are custom bent anchor bolts made domestically using 316 stainless steel material. 10-24 thread is used on one leg at approximately 7/8″ in length. An 85 degree bend was incorporate per customer’s print, with the thread containing leg measuring 1-3/4″ and the short leg measuring 1-1/2″. Lead time for smaller quantities (in the […]
Read More
