- Posted by alex@engineeredsource.com
- On April 11, 2022
- 0 Comments
These custom precision step pins were manufactured domestically in the USA using 303 stainless steel material per ASTM A581, with the raw material comprising of 3/16″ round USA melt bar stock. The outside diameter is .031″ +/- .002″ for the extended pin and .125″ +.0005/-.0000. Overall length was set to .313″ and a 45 degree […]
Read More
- Posted by alex@engineeredsource.com
- On February 18, 2022
- 0 Comments
We had these custom slotted pins manufactured domestically for our aerospace customer using DFARS compliant 303 stainless steel material. The pins measure .094″ in diameter and .35″ in overall length, with the slot at .020″ in width by .115″ in depth. The outside profile tapered from .094″ diameter max to .088″ at the narrow side. […]
Read More
- Posted by alex@engineeredsource.com
- On January 5, 2022
- 0 Comments
We supplied our customer that manufactures fire pump equipment with these custom 17-4ph precision dowel pins using 100% domestic production with DFARS compliant raw material and full certs – material certs, heat treat certs, and a certificate of conformance. The pins were produced to a diameter of .1249-.1251″ and overall length of .670-.675″ with equal […]
Read More
- Posted by alex@engineeredsource.com
- On July 30, 2021
- 0 Comments
We had 500 pieces of these large custom locating dowel pins manufactured domestically in alloy steel material, with heat treat to achieve 47-58 HRC core hardness. The original drawings were fairly aged and it was difficult to figure out how the transition point between the round and hex portions of the pins should be formed. […]
Read More
- Posted by alex@engineeredsource.com
- On July 29, 2021
- 0 Comments
We had approximately 10,000 pieces of these custom large stainless steel pins manufactured for a customer installation in Italy. 303 stainless steel was used for production and the pins measured .249″ in diameter by 5″ in overall length. A slight 45 degree chamfer was added on both sides to remove any sharp edges. This was […]
Read More
- Posted by alex@engineeredsource.com
- On July 16, 2021
- 0 Comments
These custom stainless vented pins were manufactured domestically using 303 stainless steel material and measure .393″ +/-.01 in overall length with 3/8-24 partial thread. They are fully vented with an ID of .124 +.002/-.000. A slotted drive (.03″ across) was incorporated on the threaded side and the parts were completed with a passivated finish per […]
Read More
- Posted by alex@engineeredsource.com
- On June 28, 2021
- 0 Comments
These custom internally threaded square pins were manufactured using 12L14 square bar stock material – sharp corners were absolutely critical and initial trial runs with alternative material options were unsuccessful until we finally found square bar material measuring very close to .69″ across the corners. The sharp corners allow the pins to lock at the […]
Read More
- Posted by alex@engineeredsource.com
- On October 30, 2020
- 0 Comments
These custom long stainless steel dowel pins were manufacture domestically using 303 stainless steel material. The diameter was set to 2.002mm to 2.008mm and the length was set to 100mm +/-.01mm. Full certs were provided with the parts and thorough QC testing was done on the straightness.
Read More
- Posted by alex@engineeredsource.com
- On May 26, 2020
- 0 Comments
These custom precision ground pins were manufactured in 304 stainless steel material for a medical product manufacturer. The OD of the shaft measured 6.35MM +/-.01MM and the overall length measured 152.4MM +/- .1MM. Pre-production samples were provided to our customer for approval prior to full production start. Large quantities of these custom made precision pins […]
Read More
- Posted by alex@engineeredsource.com
- On March 17, 2020
- 0 Comments
We had 3,200 pieces of these custom precision dowel pins made domestically for our medical device customer using 18-8 stainless steel material with plain finish. Overall length was set to .240″ +/- .005″ and the diameter was set to .092″ +/-.005″. These were relatively simple parts and the lead time was much faster than the […]
Read More
