Custom Stainless Steel Precision Pins – 303 Stainless Per AMS 5640 V Type 1

  • Posted by alex@engineeredsource.com
  • On October 19, 2018
  • 0 Comments
220 pieces of these custom stainless steel precision pins were produced domestically for our aerospace customer using 303 stainless steel material. Original specifications on the drawing called out for 303 stainless steel per AMS 5638 but we obtained a deviation approval to provide the part using a similar AMS 5640 V Type 1A spec material […]
Read More


Custom Low Head Metric Screws – M3 X 0.5MM X 3.25MM With Thread Locking Patch in 303 Stainless Steel Material

  • Posted by alex@engineeredsource.com
  • On October 16, 2018
  • 0 Comments
Custom low head metric screws manufactured domestically using 303 stainless steel material. The 1/16 hex drive was broached with a 1.5MM drive depth. Heavy torque blue thread locking patch was applied to conform to a .60 to .33 Nm minimum torque testing. Head height measured 1.75MM and the width at 9.65MM. The rounding around the […]
Read More


Custom A286 MS24693 Screws – Phil Flat 4-40 X 1/4″

  • Posted by alex@engineeredsource.com
  • On September 7, 2018
  • 0 Comments
These custom A286 MS24693 screws can look deceivingly simple at first glance. The A286 material was a large deviation from the typical MS24693 specifications and the parts had to be heat treated to 140 KSI. To finish off the production process the parts went through a NADCAP certified sand blast and descale & passivation process […]
Read More


Custom 316L Machined Hardware – 6MM X 1.0M Thread & Straight Nurl Application On The Nut

  • Posted by alex@engineeredsource.com
  • On September 4, 2018
  • 0 Comments
We had 100 pcs of this mating custom 316L machined hardware produced domestically with a lead time of approximately 4 weeks.  These 100 pcs were to be used in testing prior to larger volume production.  The rod pieces measures 90MM in overall length and the knurled nut measures 17MM in overall height.  Getting the nut […]
Read More


Custom Aerospace Socket Screws – NA0069A040046 Socket Head Cap Screws in 1250 MPA A286 Material

  • Posted by alex@engineeredsource.com
  • On April 25, 2018
  • 0 Comments
These are custom aerospace socket screws we had domestically produced for our aerospace customer at 50 pieces. The trickiest part was the 1250 MPA requirement that our customer insisted on, which is a deviation from the standard NA0069A040046 specification. We were able to supply the custom part faster than our original promise date at approximately […]
Read More


Alloy Steel Set Screws With Nylon Strip – DIN913 M6 X 1M X 16MM Socket Set Screw With Flat Point

  • Posted by alex@engineeredsource.com
  • On March 29, 2018
  • 0 Comments
We supply countless parts with a variety of different thread locking patches, thread locking pellets, and thread locking strip applications like these alloy steel set screws with nylon strip. These thread locking features provide for a vast variation in applications we can accommodate. We can typically provide samples to allow our customer to test different […]
Read More


Custom Modified Socket Head Screws – M4 – 0.7 X 14MM Socket Head Captive Screw in Alloy Steel Material

  • Posted by alex@engineeredsource.com
  • On January 7, 2018
  • 0 Comments
These are custom modified socket head screws in alloy steel material. Standard off the shelf M4-0.7 X 14MM socket head cap screws were modified to allow their use as captive screws with partial thread and modified head dimensions. The ground shoulder area measures 8.80MM +/- 0.3MM in length and a dimater of 3.30MM +/- 0.15MM. […]
Read More


Custom Stainless Steel Compression Springs – 302 Stainless Steel Material Per AMS 5640

  • Posted by alex@engineeredsource.com
  • On October 30, 2017
  • 0 Comments
These are custom stainless steel compression springs we supply our aerospace customer, in 302 stainless steel material to AMS 5640. The initial production run was relatively small at just 500 pieces, completed domestically with First Article Inspection Report (FAIR) and all applicable certifications. The freestanding length of the custom spring was set at 2.472 inches […]
Read More


Blue Coated Aerospace Hardware – 1/4″ Shoulder Screw In Alloy Steel With Alumazite KL-55 Blue Coating

  • Posted by alex@engineeredsource.com
  • On October 17, 2017
  • 0 Comments
This is an example of blue coated aerospace hardware we supply, with a 1/4 diameter shoulder screw in alloy steel coated with Alumazite KL-55 blue finish. The blue coating was intended to allow an robotic color coded system to recognize the screw and yet maintain its integrity in environments up to 600 degrees F. The […]
Read More


Custom Monel 400 Socket Head Cap Screws – 5/8-11 X 3-1/2 With Cut Thread

  • Posted by alex@engineeredsource.com
  • On August 29, 2017
  • 0 Comments
These are custom Monel 400 socket head cap screws measuring 5/8-11 by 3-1/2″ in length.  Domestically produced with a lead time of just 4 days, the 4 pieces we had manufactured incorporated coarse cut thread and a broached socket head drive.  Material certs and a certificate of conformance was provided with the parts per our […]
Read More
