Project Description

Production of these custom internally & externally threaded studs was run at approximately 10,000 pieces, in medium carbon grade 5 equivalent steel material.  The specific hardness requirement was set to 25-35 HRC.  The custom threaded studs had an overall length of .75″ +/.02″ with a 45-50 degree tapered point on one side.  Slotted drives were incorporated at both sides for optimal flexibility in our customer’s application.  1/2-13 thread was rolled on the outside and 1/4-20 thread tapped all the way through.

Large quantities of these custom made threaded studs would be best supplied on a 12 month blanket purchase order basis.  The Blanket Order concept allows the customer to access the large quantity cost savings without paying upfront for the entire large quantity order. Instead we take on the burden of carrying the bulk inventory and only release the parts as needed, or often on a pre-scheduled basis provided by the customer.
